생산 설비

설명

이차전지 생산 장비는 제품 개발과 상용화를 성공시키기 위해 중요한 요소입니다. 탑머티리얼은 협력업체들과 함께 고품질의 개발라인과 양산라인을 위한 전체 장비를
설계하고 제작해서 공급합니다.

전극 제조용 설비

Process Equipment
Mixing Powder feeding units,
Planetary Despa (PD) mixer,
High Disper (HD) mixer,
Binder solution mixer,
Storage tanks

Auto line control systems
Coating Comma coater,
Comma reverse coater,
Slot die coater,
Gravure coater,
Hybrid coater,
Density inspection in line
Calendering Roll presser,
Heated roll presser,
Induction heat annealing,
Thickness measurement in line
Slitting Multi lane slitter,
Surface defect inspection /
labeling in line
Logistics Auto electrode transportation
AGV and rack systems

원통형 전지 조립용 설비

Category Process Equipment
Inner cell
assembly
Electrode
drying
Vacuum drying oven
Electrode
tab welding
Ultrasonic tab welder,
Laser tab welder,
Reel to reel tab welder
Winding Semiauto reel to
reel winder,
Automatic winder
Packaging Anode tab
welding
Electric resistance
welding(ERW) and
swaging machine
Can beading Can beading machine
Electrolyte(EL) filling
@vacuum and
pressurizing
Pallet type EL filling
machine, Chamber type
EL filling machine
Cathode tab
welding
Laser welder,
Ultrasonic welder
Crimping Crimping and
sizing machine
Washing Cell washing and
tubing machine

리튬이온 파우치 전지 조립용 설비

Category Process Equipment
Inner cell
assembly
Electrode
notching
Notching machine
Electrode
drying
Vacuum drying oven
Stacking Zigzag stacking
machine
Packaging Tab welding Ultrasonic tab welding
machine, Laser tab
welding machine,

Hybrid tab welder
Pouch cup
forming
Pouch cup
forming machine
Sealing Tab side sealing
machine, Side sealing
machine
Electrolyte(EL)
filling
EL filling machine
Degassing Degassing, rolling and
sealing machine

리튬 메탈 파우치 전지 조립용 설비

Category Process Equipment
Inner cell
assembly
Cathode
notching
Universal notching
machine
Cathode
drying
Vacuum drying oven
Stacking Anode notching(laser)
and zigzag stacking
machine
Packaging Tab welding Anode(laser) and
cathode(ultrasonic)
tab welding machine
Pouch cup
forming
Pouch cup
forming machine
Sealing Tab side sealing
machine, Side sealing
machine
Electrolyte(EL)
filling
EL filling machine
Degassing Degassing, rolling
and sealing machine

알루미늄 각형 조립용 설비

Category Process Equipment
Inner cell
assembly
Electrode
notching
Universal notching
machine
Electrode
drying
Vacuum drying oven
Stacking Zigzag stacking
machine
Winding Laser notching and
winding machine
Packaging Heat pressing Heat presser
Tab welding Tab pre-welding
and top-cap
welding machine
Insulating Insulating film
assembly machine
Can / cap
welding
Can / cap laser
welding and leak
checking machine
Electrolyte(EL)
filling
EL filling machine
Sealing Seal-pin welding and
leak checking machine

포메이션 및 전지 성능 테스트 설비

Category Process Equipment
Formation Pre-formation Pre-formation system
(with degassing)
Aging / Storage Rack system
Formation Charge /
Discharge system
Grading Rank sorting machine
IR / OCV ACR, DCR, OCV
measuring system
Logistics Auto crane system
Test Cycle test Cycler
Chamber Temperature
controlled chambers
(with fire extinguisher)
